Location and Function of Controls
2-3 5975977 BARCODATA 708 260597
Back light key : when activated, all keys will be lit up and
visible in the dark.
ADJ. : adjust key, to enter or exit the adjustment mode.
Address key (recessed key), to enter the address of the
projector (between 0 and 9). Press the address key,
followed by pressing one digit button between 0 and 9.
STBY : stand by button :
- to initiate remote power up operation
- to stop projection without main power off.
Pause :to blank the image, press PAUSE. The image
disappears but full power is retained for immediate restart-
ing.
Digit buttons : direct input selection.
Picture controls : use these buttons to obtain the desired
level (see also 'Controlling') for each picture function.
1
2
3
4
TEXT : when adjusting one of the image controls during a
meeting, the displayed bar scale can be removed by
pressing 'TEXT' key first. To re-display the bar scale on the
screen, press 'TEXT' key again. 'TEXT' key is only active
in operational mode. When 'TEXT' is off, no warning
message will be displayed.
ENTER : to start up the adjustment mode or to confirm an
adjustment or selection in the adjustment mode.
EXIT : to leave the adjustment mode or to scroll upwards
when in the adjustment mode.
Control disk : to make menu selections when in the
adjustment mode. Also allows to increment or decrement
an adjustment in the adjustment mode.
control disk up = up arrow in the menus
control disk down = down arrow in the menus
control disk to the right = arrow to the right on the menus
control disk to the left = arrow to the left on the menus
RC operating indication : lights up when a button on the
remote control is pressed. (This is a visual indicator to
check the operation of the remote control)
