Random Access Adjustment Mode
6-1 5975977 BARCODATA 708 260597
6
RANDOM ACCESS ADJUSTMENT MODE
Starting up the random access adjustment mode.
ADJUSTMENT MODE
Select a path from
below:
Select with or
then
to return
source 1
GUIDED
RANDOM ACCESS
INSTALLATION
SERVICE
IRIS
Push the control disk up or down to highlight "RANDOM AC-
CESS" and then press ENTER .
Some items in the Random access mode are password protected
(when the password function is enabled). Enter your password
to continue. All other password protected items are now also
available if you stay in the adjustment mode.
ENTER continues to Setup Pattern Selection
EXIT returns to operational mode
RANDOM ACCESS
ADJUSTMENT MODE
PICTURE TUNING
SETUP PATTERN SELECTION
H PHASE
RASTER SHIFT
V CENTERLINE BOW
SIDE BOW
V CENTERLINE SKEW
SEAGULL CORRECTION
SIDE KEYSTONE
LEFT-RIGHT (E-W)
H CENTERLINE BOW
TOP KEYSTONE
H CENTERLINE SKEW
BOTTOM KEYSTONE
TOP BOW
BOTTOM BOW
TOP-BOTTOM (N-S)
SEAGULL CORRECTION
SIZE
BLANKING
BOTTOM KEYSTONE
TOP BOW
BOTTOM BOW
SEAGULL CORRECTION
GEOMETRY
CONVERGENCE
COLOR SELECT
Overview 'random Access Adjustment' mode.
VER LINEARITY
COLOR BALANCE
SYNC
LINE DOUBLER
PORT 2
