Random Access Adjustment Mode
6-4 5975977 BARCODATA 708 260597
Line Doubler (option)
Line doubling is only possible for Video, S-Video, Component
Video images on standard line frequency and RGB signals on 15
kHz.
To eliminate the video line patterns and to improve the image
stability, the line doubler has to be switched on. The line doubler
is default set in the ON position when starting up for the first time.
The setting of the line doubler will be saved together with the
source number. Each time this source number is selected, the
last saved version will be loaded.
Highlight Line Doubler with the control disk and press ENTER to
toggle between ON (active) and OFF (non active).
EXIT will return to the random access selection menu.
Port 2 : S-Video/Video
Port 2 can be used as Video or S-Video input.
Highlight
Port 2 by pushing the control disk up or down and press
ENTER to toggle between Video and S-Video .
Select with or
to accept
to return.
PICTURE TUNING
COLOR BALANCE
SYNC : FAST
PEAKING : ON
LINE DOUBLER : ON
Select with or
to accept
to return.
PICTURE TUNING
COLOR BALANCE
SYNC : FAST
PEAKING :ON
LINE DOUBLER : ON
PORT 2 : S-VIDEO
Select with or
to accept
to return.
Peaking
Peaking improves the contours in an projected image.
Highlight
PEAKING by pushing the control disk up or down and press
ENTER to toggle the peaking between OFF and ON.
During the creation of new settings for a RGB source the peaking is
switched to OFF.
PICTURE TUNING
COLOR BALANCE
SYNC : FAST
PEAKING : OFF
LINE DOUBLER : ON
Color Select
Highlight COLOR SELECT by pushing the control disk up or down
and press ENTER to display the color select menu.
Select with or
to accept
to return.
Select with or
to accept
to return.
COLOR SELECT
RED
GREEN
BLUE
RED AND GREEN
BLUE AND GREEN
RED AND BLUE
ENTER continues to the color select menu.
EXIT will return to Internal Crosshatch Selection or Setup
Pattern Selection Menu.
ADJUST returns to operational mode.
Use the control disk to highlight a color (CRT) or combination of
colors to display the projected image in that specific color.
To select a new color, press
ENTER , the color selection menu
appears again on the screen. To terminate the color select proce-
dure, press
EXIT .
ENTER continues with the selected color or color combina-
tion.
EXIT returns to the Random access main menu.
RANDOM ACCESS
ADJUSTMENT MODE
PICTURE TUNING
GEOMETRY
CONVERGENCE
COLOR SELECT
