CONTROLLING
Battery installation in the RCU.
A new battery is delivered inside the plastic bag with the power cord. Before using the RCU, install
first the battery.
Remove the battery cover on the backside of the remote control by pushing the indicated handle a
little to the bottom of the RCU. Lift up the top side of the cover at the same time (fig. 1).
Insert the new 9 V battery (E-block type, e.g. 6F22S or equivalent) in the lower compartment and
connect the battery to the contact plate.
Insert the battery into the lower compartment and put the cover back.
Caution : Do not display a stationary image with full brightness
and contrast for longer than 20 min., otherwise you risk damage
to the CRT's.
fig.1
310a.DRW
fig.2
Battery
Contact
plate
Insert here,
behind the
plastic cover, the
'Insert card for
RCU'. You can
cut out this card
on one of the
last pages of this
manual.
