354 | LSN Peripherals | LSN Magnetic Contacts
Technical Specifications
Type of installation Surface mount, parallel or head-on
Operating voltage Max. 33 V_
Reed contacts Normally open contact
Switch tolerance ≥ 10 7
Magnet AlNiCo 500
Switch dimension: Ø 8 mm x 30 mm
Magnet dimension: Ø 8 mm x 30 mm
Installation distance 5 to 20 mm
AG4 surface mounting housing
(H x W x D)
12 x 11.8 x 42.8 mm
Temperature range -25 °C to 70 °C
Connection cable: 4 m, LiY(St) Y 4 x 0.14 mm
with screen, exterior Ø 3.2 mm
Protection category IP68
Wire colors aLSN: 2 x white
b1LSN: brown
b2LSN: yellow
