9 8
a
b
c
7
6
3 4 5 2 1
1 Displays that the rear window heating setting
is on.
2 Displays that the front window heating setting
is on.
3 Displays that the internal circulation mode
setting is on.
4 Displays that the A/C setting is on.
5 Displays that the dual A/C function is on.
6 Displays the seat heating setting for the right
seat.
7 Displays the internal temperature setting for
the right seat.
8 Displays the fan speed.
9 Displays the fan direction.
a The previous screen returns.
p If you do not operate the climate control
panel for a few seconds, the previous
screen is displayed automatically.
b Displays the internal temperature setting for
the left seat.
c Displays the seat heating setting for the left
seat.
Engb
172
Chapter
28 Displaying the operation status of vehicle equipment
