2 Push the lower part of the detachable
faceplate until you hear a click.
If you fail to successfully attach the detach-
able faceplate to the navigation system, try
again but be careful not to force it as the
panel could be damaged.
Adjusting the LCD panel angle
p This function is available for AVIC-F40BT
only.
WARNING
Keep hands and fingers clear of the unit when
opening, closing, or adjusting the LCD panel. Be
especially cautious of children
’s hands and fin-
gers.
CAUTION
Do not open or close the LCD panel by force. This
may cause malfunction.
1 Press the h button.
The
“Monitor Setup” screen appears.
2 Touch or to adjust the angle.
3 Touch .
p The adjusted angle of the LCD panel will be
memorised and the LCD panel will automa-
tically return to that angle the next time the
LCD panel is opened or closed.
Inserting and ejecting a disc
Inserting a disc (for AVIC-F40BT)
WARNING
! Keep hands and fingers clear of the unit when
opening, closing, or adjusting the LCD panel.
Be especially cautious of children
’s hands
and fingers.
! Do not use with the LCD panel left open. If
LCD panel is left open, it may result in injury
in the event of an accident.
CAUTION
! Do not open or close the LCD panel by force.
This may cause malfunction.
! Do not operate this navigation system until
the LCD panel completely opens or closes. If
this navigation system is operated while the
LCD panel is opening or closing, the LCD
panel may stop at that angle for safety.
! Do not place a glass or a can on the open
LCD panel. Doing so may break this naviga-
tion system.
! Do not insert anything other than a disc into
the disc-loading slot.
1 Press the h button.
The
“Monitor Setup” screen appears.
2 Touch [Open].
The LCD panel opens, and the disc-loading
slot appears.
Engb
15
Chapter
02
Basic
operation
Basic operation
