Section One
Chapter 1
Contents
Section One
01 Contents............................................................ 4
What’s in the box .......................................................... 4
02 Speaker Setup Guide ....................................... 5
Safety precautions when setting up .............................. 5
Home theater sound setup ........................................... 5
Wall mounting the center speaker ................................ 7
Before mounting ........................................................ 7
Additional notes on speaker placement ........................ 7
03 Connecting up .................................................. 8
Basic connections ........................................................ 8
Using this system for TV audio .................................... 11
04 Remote control............................................... 12
Using the remote control ............................................ 14
Putting the batteries in the remote control ................. 15
05 Before you start ............................................. 16
Switching on .............................................................. 16
Setting up ................................................................... 16
Basic operation .......................................................... 17
Watching a DVD ...................................................... 17
Listening to a CD ...................................................... 17
Watching a title recorded on the HDD ..................... 17
Listening to the radio ............................................... 17
Section Two
Operating instructions for the Audio
Multi-channel Receiver Subwoofer and
Speaker System . . . . . . . . . . . . . . . . . . . . . 18
Section Three
Operating instructions for the DVD
Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
What’s in the box
Please confirm that the following items are all supplied.
Receiver subwoofer (SX-SW505HX) box:
• Remote control (page 12)
• AA/R6 dry cell batteries (to confirm operation) x2
(page 15)
• Display unit (page 20)
• Power cord (page 10)
• AM loop antenna (page 8)
• FM wire antenna (page 8)
• Control cable (page 8)
• Display cable (page 8)
• Coaxial cable (page 8)
• Microphone (for Auto MCACC setup) (page 21)
• These operating instructions
• Warranty card
DVD recorder (DVR–545HX-S) box:
• Remote control
• AA/R6 dry cell batteries x2
• Audio / video cable (red/white/yellow) (page 11)
• G-LINK™ cable (page 49)
• RF antenna cable x2 (1.5 m and 30 cm) (page 11)
• Power cord (page 11)
• Operating instructions
• Warranty card
Speakers (S–ST606) box:
• Speakers (front x2, surround x2, center x1) (page 10)
• Speaker cables x5 (page 9)
• Non-skid pads (large) x4 (page 5)
• Non-skid pads (large) x16 (page 5)
• Non-skid pads (small) x4 (page 5)
• Speaker stand bases x4 (page 5)
• Screws (for bases) x12 (page 5)
