The Video Adjust menu 15
128
En
3 Select the picture quality setting you want to adjust.
You can adjust the following settings:
• Prog. Motion – Adjusts the motion and still picture
quality when video output is set to progressive. (Prog.
Motion is ineffective when PureCinema is On.)
• PureCinema – This setting optimizes the picture for
film material when the video output is set to
progressive. Usually set to
Auto 1 but try switching
to Auto 2, On or Off if the picture appears unnatural.
• Subtitle Adjust – When the video output is set to
progressive scan, it’s possible that the subtitles in
some movies will disappear unnaturally. In this case
select the
On setting (only possible when connected
using HDMI).
• YNR – Adjusts the amount of noise reduction (NR)
applied to the Y (brightness) component.
• CNR – Adjusts the amount of noise reduction (NR)
applied to the C (colour) component (only possible
when connected using HDMI).
• BNR – Adjusts the amount of noise reduction (NR)
applied to the block noise (artefacts visible in areas of
flat colour, caused by MPEG compression).
• MNR – Adjusts the amount of noise reduction (NR)
applied to the mosquito noise (artefacts visible
around the edges of an image, caused by MPEG
compression).
• Sharpness – Adjusts the sharpness of the high-
frequency (detailed) elements in the picture.
• Detail – Adjusts how sharp edges appear.
• White Level – Adjusts the intensity of white.
• Black Level – Adjusts the intensity of black.
• Black Setup – Corrects the standard reference black
level (NTSC video playback on the
Interlace video
output setting only). (Black Setup is ineffective for
HDMI output.)
• Gamma Correction – Adjusts the brightness of
darker images.
• Hue – Adjusts overall balance between red and
green.
• Chroma Level – Adjusts how rich the colours
appear.
4 Use the / buttons to adjust the currently
selected picture quality setting.
5 When you have all the settings as you want
them, press HOME MENU to exit.
Tip
• To see more of the picture as you adjust different
settings, press ENTER after selecting the setting you
want to adjust.
• YNR and Detail are ineffective for analog and
component video when the Video Priority Mode is set
to
HDMI. Set to Component to make effective for
both analog and HDMI video. See page 137.
Memory1
Subtitle Adjust
YNR
Motion Still
PureCinma
Prog. Motion
Auto1
Off Max
Off Max
BNR
MNR Max
Max
Off
Min
CNR
On
