The Initial Setup menu 16
131
En
Analog Tuner
Auto Channel Setting Auto Scan Select your country and then wait for the recorder to auto tune into channels
in your area. After auto scan has finished, the channel mapping screen
appears showing which channels have been assigned to which program
numbers. You can skip unwanted channels using the Manual CH Setting
option below.
Press
HOME MENU to exit the channel mapping screen.
Download from TV If your TV supports this feature you can download all the channels that
your TV is tuned to via the SCART input. Select your country and then wait
for the download to complete. After the download is complete, the channel
mapping screen appears, as above.
See also the operating instructions that came with your TV for more
information.
Manual CH Setting Next Screen Proceed to the next screen if you need to adjust any of the settings made
by auto tuning. Select your country, then proceed to the manual channel
setting screen:
• Change channel presets using the
PREV/ NEXT buttons.
• To skip the displayed channel (because there is no station assigned to
that channel), change the
Skip setting to On.
• Set the CH SYSTEM setting to match the channel system of your country
or region.
• Set the
CHANNEL setting to the channel you want to assign to the current
channel preset.
• To manually fine tune the channel, change the
AFT setting to Off then
adjust the Level setting.
• Set the Sound System setting to match the sound system of your region.
• The Name field allows you to input a name of up to five characters for
the current channel preset.
• If the currently selected channel is scrambled requiring a decoder
connected to the
AV2(INPUT 1/DECODER), set the Decoder setting to On.
Channel Swapping Next Screen Proceed to the next screen to swap channel assignments of different
presets so that you can group together presets that naturally go together.
Select two presets to swap then press
ENTER.
Setting Options Explanation
