Wiring and Connections - UDM Receivers
15
UDM-0404 4x4 Multi-Format Distribution Hub
UDM-RX02 Product Specifications
UDM-RX02 Specifications
Power Requirements:
24VDC @ .75A
Note: In most cases the UDM-RX02 is remotely powered by the UDM Multi-
Format Distribution Hub (see Powering on the UDM-RX02 ).
Rear Panel Connectors:
Power Socket:
2.1mm barrel-style DC power socket (female)
UDM Hub (RJ45) Port:
Provides audio/video transport as well as control via Cat5, Cat5e or Cat6 to
an UDM Hub.
Serial (RJ12) port:
Enables an administrator to control the various functions to the UDM-RX02
from a command line prompt and terminal connection.
• Requires a DB9-to-RJ12 adapter cable (FG-RS01) to connect to a PC.
• 9600, 8 bit, No Parity, 1 Stop Bit
IR Rx Port:
3.5mm stereo input port, for connection of an IR receiver to allow setup of
the UDM-RX02, local compensation controls, and remote control of cen-
trally located IR devices.
IR Tx Port:
3.5mm stereo IR Transmitter output port allows one IR-controlled device
(such as a DVD or VCR player) to be controlled via optional wired IR emit-
ter.
Audio Connectors:
• Black RCA female connector - Digital audio
• White RCA female connector - Analog audio Left
• Red RCA female connector - Analog audio Right
Video Connectors:
• Yellow RCA female connector - CVBS (supports composite video)
• S-Video - S-video female connector
• VGA - HD15 female connector (supports VGA video)
• Green RCA female connector - Component output: Y
• Blue RCA female connector - Component output: Pb
• Red RCA female connector - Component output: Pr
Operating Environment:
• 35°F - 95°F (5°C - 35°C)
• Max. relative humidity - 85% (non-condensing)
Dimensions (HWD):
1" x 8 15/16” x 3 3/8” (25 mm x 227 mm x 85 mm)
Weight:
1.45 lb. (658 g)
Certifications:
• CE
• FCC part 15 Class A
Other AMX Equipment:
• RS232 DB9/RJ12 Connection Cable (FG-RS01)
• UDM-RC02 Multi-Format IR Remote Control (FG-UDM-RC02)
• IR01 IR Emitter Module (FG-IR01)
• IR03 External IR Receiver Module (FG-IR03)
• UDM-PS 24VDC, 750mA Power Supply (FG-UDM-PS)
