8200 Series Converged Network Adapter and 3200 Series Intelligent Ethernet Adapter
Page
80
Interrupt Test The interrupt test checks the ability of the hardware to create an interrupt and the ability of
the driver to process the interrupt by forcing the generation of a predetermined number of interrupts. The
test succeeds if the device generates the interrupts and the driver processes all interrupts expected.
Loopback Test The loopback test is a diagnostic tool that routes transmit data through a loopback
connector back to the same adapter.
Link Test The link test inspects the link status (up or down) by checking the physical communication
channel between the host and the firmware.
Windows Diagnostic Test Messages
If a test fails, an appropriate error code is generated and displayed, as shown in Table 17. Note that this
table does not list error messages for the interrupt and link tests.
Table 17. Windows Diagnostic Test Messages
Test
Error Message
Description
Loopback
LB_TEST_OK
Loopback test has passed
LB_SEND_WAIT_QUEUE
_ERR
Send queue blocked
LB_NORCV_ERR
Receive packet not received
LB_NOMEM_ERR No
memory
error
LB_TX_QUEUE_ERR
Transmit queue error
LB_SHORT_DATA_ERR
Looped data short error
LB_SEQUENCE_ERR
Looped data out of sequence
LB_DATA_ERR
Looped data corrupted
LB_ERR_CNT
Looped error count
Register
CR_TEST_OK
Control register test passed
CR_NIU_MODE
Network interface unit (NIU) error
CR_PHY
Physical layer (PHY) error
CR_ERRCNT
Control register error count
Hardware
HW_TEST_OK
Hardware test has passed
HW_DMA_BZ_0
DMA channel 0 is busy
HW_DMA_BZ_1
DMA channel 1 is busy
HW_DMA_BZ_2
DMA channel 2 is busy
HW_DMA_BZ_3
DMA channel 3 is busy
HW_SRE_PBI_HALT
Segmentation and reassembly engine currently halted
HW_SRE_L1IPQ
Segmentation and reassembly engine currently paused due
to L1 IPQ discard failure
HW_SRE_L2IPQ
Segmentation and reassembly engine currently paused due
to L2 IPQ discard failure
