8200 Series Converged Network Adapter and 3200 Series Intelligent Ethernet Adapter
Page
79
For every test performed, the diagnostic utility shows the following data:
• Total number of attempts
• Number of successful completions
• Number of failures
You can either perform all tests in succession, or perform only specific tests specified by the preceding
command-line parameters.
You can run additional diagnostics in the CLI as listed in the following table. To determine the
cna_port_inst
, issue the qaucli -nic –i command as shown in Table 16.
Windows Diagnostic Test Descriptions
This section provides descriptions of the following Windows diagnostic tests:
Hardware Test The hardware test checks the status of various hardware blocks, including DMA engines,
receive engine, and on-board processor meta cores.
Register Test The register test performs device register read/write accesses.
Table 16. Running Windows Diagnostic Tests in the CLI
Test Type
Command
External Loopback
qaucli -nic -extloopback <
cna_port_inst> <tests_num> <on_error>
Where <tests_num> specifies the number of tests, 1–65535, and <on_error> is
either 0=Ignore or 1=Abort.
Note: This test requires a pass-through module to be configured for both ports. Test
runs between two ports. Single port loopback is not supported.
Flash
qaucli –nic –testflash [cna_port_inst]
Hardware
qaucli –nic –testhw [cna_port_inst]
Internal Loopback
qaucli -nic -intloopback <cna_port_inst> <tests_num> <
on_error>
Where <tests_num> specifies the number of tests, 1–65535, and <on_error> is
either 0=Ignore or 1=Abort
Interrupt
qaucli –nic –testinterrupt [cna_port_inst]
Link
qaucli -nic -testlink [cna_port_inst]
Ping (IPv4)
qaucli -nic -ping <
cna_port_inst> <hostname_or_IPv4> [<count> <pock-
et_size> <timeout_ms> <TTL>]
Where the default values are count=5, pocket_size=525, time-
out_ms=1000
, and TTL=30
Register
qaucli -nic -testregister [cna_port_inst]
Transceiver DMI Data
qaucli -nic -trans [cna_port_inst]
