8200 Series Converged Network Adapter and 3200 Series Intelligent Ethernet Adapter Page 97
Appendix A. Adapter LEDs
The LED behavior for the 824x and 324x Series Adapters is defined in Table 18, except for the 3242-RJ
Adapter, which is defined in Table 19.
Table 18. QLE824x and QLE324x LED Scheme
Link LED Activity LED Activity
Off Off Power off
Off Off Power on (no link)
On On Power on/link established, no activity
On Flashing Power on/link established, LAN and/or SAN activity
Table 19. QLE3242-RJ LED Scheme
Link LED Activity LED Activity
Off Off Power off
Off Off Power on (no link)
Orange on Green on Power on (10Gbps link, no traffic)
Orange on Green flashing Power on (10Gbps link, traffic running)
Green on Green on Power on (1Gbps link, no traffic)
Green on Green flashing Power on (1Gbps link, traffic running)
Off Green on Power on (100Mbps link, no traffic)
Off Green flashing Power on (100Mbps link, traffic running)
Green flashing Green flashing Beacon on
