8200 Series Converged Network Adapter and 3200 Series Intelligent Ethernet Adapter
Page
69
A window opens that displays the statistics (Figure 48).
Figure 48: eSwitch Statistics for Function 0
3. After reviewing the statistics, click OK or Cancel to close the pop-up window.
NPAR Setup
This section provides NPAR reference tables you can use when configuring NIC partitions using the
various tools available.
Default Settings
Before configuring NIC partitions, the 8200 and 3200 Series Adapters appear as a simple dual-port 10GbE
adapter with the NPAR settings shown in Table 7.
Table 7. Default Configuration
Function
Number
Function Type
Physical
Port Number
Minimum
Bandwidth
(%)
Maximum
Bandwidth
(%)
Default
Function Type
0
NIC
0
0
100
Enabled as NIC
1
NIC
1
0
100
Enabled as NIC
