8200 Series Converged Network Adapter and 3200 Series Intelligent Ethernet Adapter
Page
70
Configuration Options
Depending on your system requirements and operating environment, you may set up the 8200 and 3200
Series Adapters’ port partitions to support different function types. Table 8 shows the available function
types and configurable parameters.
Table 8. Configuration Options
Function
Number
Function Type
Physical
Port Number
Minimum
Bandwidth
a
(%)
a
Minimum Bandwidth: Minimum guaranteed bandwidth, specified as a percentage of the link speed. The total across all partitions will add up to less than
the maximum link bandwidth. The queue’s rate will be allowed to exceed the specified value up to max-rate, if excess bandwidth is available on the
physical port link.
Maximum
Bandwidth
b
(%)
b
Maximum bandwidth: Maximum allowed bandwidth, specified as a percentage of the link speed. The queue’s rate will not be allowed to exceed the
specified value, even if excess bandwidth is available on the physical port link. The total across all partitions may not be greater than the maximum link
bandwidth.
Default Function Type
0
NIC
0
0
100
NIC
1
NIC
1
0
100
NIC
2
Disabled/NIC
0
0
100
NIC
3
Disabled/NIC
1
0
100
NIC
4
iSCSI/NIC/Disabled
0
0
100
iSCSI
5
iSCSI/NIC/Disabled
1
0
100
iSCSI
6
FCoE/NIC/Disabled
0
0
100
FCoE
7
FCoE/NIC/Disabled
1
0
100
FCoE
