4.
Select
the
startup
device.
The
next
time
the
server
is
started,
it
returns
to
the
startup
sequence
that
is
set
in
the
Configuration/Setup
Utility
program.
Enabling
the
Broadcom
Gigabit
Ethernet
Utility
program
The
Broadcom
Gigabit
Ethernet
Utility
program
is
part
of
the
BIOS.
You
can
use
it
to
configure
the
network
as
a
startable
device,
and
you
can
customize
where
the
network
startup
option
appears
in
the
startup
sequence.
Enable
and
disable
the
Broadcom
Gigabit
Ethernet
Utility
program
from
the
Configuration/Setup
Utility
program.
To
enable
the
Broadcom
Gigabit
Ethernet
Utility
program,
complete
the
following
steps:
1.
Turn
on
the
server.
2.
When
the
prompt
Press
F1
for
Configuration/Setup
appears
during
startup,
press
F1.
3.
From
the
Configuration/Setup
Utility
main
menu,
select
Devices
and
I/O
Ports
and
press
Enter.
4.
Select
Planar
Ethernet
and
use
the
Right
Arrow
(→)
key
to
set
it
to
Enabled.
5.
Select
Save
Settings
and
press
Enter.
Configuring
the
Broadcom
Gigabit
Ethernet
controller
The
Ethernet
controller
is
integrated
on
the
system
board.
It
provides
an
interface
for
connecting
to
a
10-Mbps,
100-Mbps,
or
1-Gbps
network
and
provides
full-duplex
(FDX)
capability,
which
enables
simultaneous
transmission
and
reception
of
data
on
the
network.
If
the
Ethernet
ports
in
the
server
support
auto-negotiation,
the
controller
detects
the
data-transfer
rate
(10BASE-T,
100BASE-TX,
or
1000BASE-T)
and
duplex
mode
(full-duplex
or
half-duplex)
of
the
network
and
automatically
operates
at
that
rate
and
mode.
You
do
not
have
to
set
any
jumpers
or
configure
the
controller.
However,
you
must
install
a
device
driver
to
enable
the
operating
system
to
address
the
controller.
To
find
updated
information
about
configuring
the
controller,
complete
the
following
steps.
Note:
Changes
are
made
periodically
to
the
Lenovo
Web
site.
The
actual
procedure
might
vary
slightly
from
what
is
described
in
this
document.
1.
Go
to:
2.
From
Family
list,
select
ThinkServer
TD100
or
TD100x,
and
click
Continue.
3.
Click
Downloads
and
drivers
to
download
firmware
updates.
Chapter
4.
Configuring
the
server
59
