Creating a raid array, Viewing the array configuration, Using the baseboard management controller – Lenovo ThinkServer TD100x User Manual
Page 73: Using, Baseboard, Management, Controller
v
Disk
Utilities
Select
this
choice
to
format
a
disk
or
verify
the
disk
media.
Select
a
device
from
the
list
and
read
the
instructions
on
the
screen
carefully
before
making
a
selection.
Starting
the
Adaptec
RAID
Configuration
Utility
program:
To
start
the
Adaptec
RAID
Configuration
Utility
program,
complete
the
following
steps:
1.
Turn
on
the
server.
2.
When
the
prompt
Press
for
Adaptec
RAID
Configuration
Utility
appears,
press
Ctrl+A.
3.
To
select
a
choice
from
the
menu,
use
the
arrow
keys
to
highlight
it
and
press
Enter.
Creating
a
RAID
array
To
use
the
Adaptec
RAID
Configuration
Utility
program
to
configure
a
RAID
level-1
array,
complete
the
following
steps:
1.
Start
the
Adaptec
RAID
Configuration
Utility
program.
2.
Select
Array
Configuration
Utility.
3.
Select
Create
Array.
4.
From
the
list
of
ready
drives,
select
the
two
drives
that
you
want
to
group
into
the
array.
5.
When
you
are
prompted
to
select
the
RAID
level,
select
RAID
0
or
RAID-1.
6.
(Optional)
Type
an
identifier
for
the
array.
7.
When
you
are
prompted
for
the
array
build
method,
select
Quick
Init.
8.
Follow
the
instructions
on
the
screen
to
complete
the
configuration,
and
select
Done
to
exit.
9.
Restart
the
server.
Viewing
the
array
configuration
To
view
information
about
the
RAID
array,
complete
the
following
steps:
1.
Start
the
Adaptec
RAID
Configuration
Utility
program.
2.
Start
the
Array
Configuration
Utility.
3.
From
the
Array
Configuration
Utility
window,
select
Manage
Arrays.
4.
Select
an
array
and
press
Enter.
5.
Press
Esc
to
exit
from
the
program.
For
additional
information
about
using
the
Adaptec
RAID
Configuration
Utility
program
to
create,
configure,
and
manage
arrays,
see
the
documentation
on
the
IBM
ServeRAID-8kl
(Adaptec
HostRAID)
Support
CD.
Using
the
baseboard
management
controller
The
baseboard
management
controller
(BMC)
provides
environmental
monitoring
for
the
server.
If
environmental
conditions
exceed
thresholds
or
if
system
components
fail,
the
baseboard
management
controller
lights
LEDs
to
help
you
diagnose
the
problem
and
also
records
the
error
in
the
System
Event/Error
log.
The
baseboard
management
controller
also
provides
the
following
remote
server
management
capabilities:
v
Command-line
interface
(IPMI
Shell)
Chapter
4.
Configuring
the
server
57
