Chapter
3.
Server
controls,
LEDs,
and
power
This
chapter
describes
the
controls
and
light-emitting
diodes
(LEDs)
and
how
to
turn
the
server
on
and
off.
Front
view
The
following
illustration
shows
the
controls,
LEDs,
and
connectors
on
the
front
of
the
hot-swap
server
models.
1
System
power
LED
6
CD-eject
or
DVD-eject
button
2
Power-control
button
7
Hot-swap
hard
disk
drive
status
LED
(amber)
3
Hard
disk
drive
activity
LED
8
Hot-swap
hard
disk
drive
activity
LED
(green)
4
System-error
LED
9
CD
or
DVD
drive
activity
LED
(green)
5
USB
connectors
10
Front
information
panel
©
Lenovo
2008,
2009.
Portions
©
IBM
Corp.
2007.
41
