EP7311
High-Performance, Low-Power System on Chip
SDRAM Burst Read Cycle
Note: 1. Timings are shown with CAS latency = 2
2. The SDCLK signal may be phase shifted relative to the rest of the SDRAM control and data signals due to uneven loading.
Designers should take care to ensure that delays between SDRAM control and data signals are approximately equal.
ADRAS ADCAS
SDCLK
SDCS
SDRAS
SDCAS
SDQM
[0:3]
ADDR
DATA
SDMWE
D1 D4 D3 D2
t
ADv
t
ADv
t
CSd
t
CSa
t
CSa
t
CAa
t
RAd
t
CSd
t
CAd
t
RAa
t
DAh
t
DAs
t
DAh
t
DAs
t
DAh
t
DAs
t
DAh
t
DAs
t
RAnv
Figure 4. SDRAM Burst Read Cycle Timing Measurement
