16

Copyright Cirrus Logic, Inc. 2011

(All Rights Reserved)

DS506F2

EP7311
High-Performance, Low-Power System on Chip

SDRAM Interface

Figure 3

through

Figure 6

define the timings associated with all phases of the SDRAM. The following table contains the values for

the timings of each of the SDRAM modes.

Parameter

Symbol

Min

Typ

Max

Unit

SDCLK rising edge to SDCS assert delay time

t

CSa

0

2

4

ns

SDCLK rising edge to SDCS deassert delay time

t

CSd

 3

2

10

ns

SDCLK rising edge to SDRAS assert delay time

t

RAa

1

3

7

ns

SDCLK rising edge to SDRAS deassert delay time

t

RAd

 3

1

10

ns

SDCLK rising edge to SDRAS invalid delay time

t

RAnv

2

4

7

ns

SDCLK rising edge to SDCAS assert delay time

t

CAa

 2

2

5

ns

SDCLK rising edge to SDCAS deassert delay time

t

CAd

 5

0

3

ns

SDCLK rising edge to ADDR transition time

t

ADv

 3

1

5

ns

SDCLK rising edge to ADDR invalid delay time

t

ADx

 2

2

5

ns

SDCLK rising edge to SDMWE assert delay time

t

MWa

 3

1

5

ns

SDCLK rising edge to SDMWE deassert delay time

t

MWd

 4

0

4

ns

DATA transition to SDCLK rising edge time

t

DAs

2

-

-

ns

SDCLK rising edge to DATA transition hold time

t

DAh

1

-

-

ns

SDCLK rising edge to DATA transition delay time

t

DAd

0

-

15

ns
