CS61880
40 DS450PP3
14.26 AWG Enable Register (19h)
14.27 Reserved Register (1Ah)
14.28 Reserved Register (1Bh)
14.29 Reserved Register (1Ch)
14.30 Reserved Register (1Dh)
14.31 Bits Clock Enable Register (1Eh)
14.32 Reserved Register (1Fh)
14.33 Status Registers
The following Status registers are read-only: LOS
Status Register (04h) (See Section 14.5 on
page 35), DFM Status Register (05h) (See Sec-
tion 14.6 on page 35) and AIS Status Register
(13h) (See Section 14.20 on page 38). The
CS61880 generates an interrupt on the INT pin any
time an unmasked status register bit changes.
BIT NAME Description
[7:0] AWGN 7-0
The AWG enable register is used for selecting the source of the customized transmission
pulse-shape. Setting bit n to “1” in this register selects the AWG as the source of the output
pulse shape for channel n. When bit n is set to “0” the pre-programmed pulse shape in the
ROM is selected for transmission on channel n. (Refer to
Arbitrary Waveform Generator
(See Section 15 on page 42). Register bits default to 00h after power-up or reset.
BIT NAME Description
[7:0]
RSVD 7-0 RESERVED
BIT NAME Description
[7:0]
RSVD 7-0 RESERVED
BIT NAME Description
[7:0] RSVD 7-0 RESERVED
BIT NAME Description
[7:0] RSVD 7-0 RESERVED
BIT NAME Description
[7:0] BITS 7-0 Writing a “1” to bit n in this register changes channel n to a stand-alone timing recovery unit
used for G.703 clock recovery. (Refer to
BUILDING INTEGRATED TIMING SYSTEMS
(BITS) CLOCK MODE (See Section 8 on page 23) for a better description of the G.703 clock
recovery function). Register bits default to 00h after power-up or reset.
BIT NAME Description
[7:0] RSVD 7-0 RESERVED
