14.14 LOS/AIS Mode Enable Register (0Dh)
14.15 Automatic TAOS Register (0Eh)
14.16 Global Control Register (0Fh)
BIT NAME Description
[7:0] LAME 7-0 Setting bit n to “1” enables ETSI 300 233 compliant LOS/AIS for channel n; setting bit n to “0”
enables ITU G.775 compliant LOS/AIS for channel n. Register bits default to 00h after
power-up or reset.
BIT NAME Description
[7:0] ATAO 7-0 Setting bit n to “1” enables automatic TAOS generation on channel n when LOS is detected.
Register bits default to 00h after power-up or reset.
BIT NAME Description
This register is the global control for the AWG Auto-Increment, Automatic AIS insertion,
encoding/decoding and the jitter attenuators location, FIFO length and corner frequency for
all eight channels. Register bits default to 00h after power-up or reset.
[7] AWG Auto-
Increment
The AWG Auto-Increment bit indicates whether to auto-increment the AWG Phase Address
Register (17h) (See Section 14.24 on page 39) after each access. Thus, when this bit is set,
the phase samples address portion of the address register increments after each read or
write access. This bit must be set before any bit in the AWG Enable register is set, if this
function is required.
[6] RAISEN
On LOS, this bit controls the automatic AIS insertion into all eight receiver paths.
0 = Disabled
1 = Enabled
[5] RSVD RESERVED (This bit must be set to 0.)
[4] CODEN
Line encoding/decoding Selection
0 = HDB3
1 = AMI
[3] FIFO
LENGTH
Jitter Attenuator FIFO length Selection
0 = 32 bits
1 = 64 bits
[2] JACF
Jitter Attenuator Corner Frequency Selection
0 = 1.25 Hz
1 = 2.50 Hz
[1:0] JASEL [1:0]
These bits select the position of the Jitter Attenuator.
Table 11. Jitter Attenuator Position Selection
JASEL 1 JASEL 0 POSITION
0 0 Disabled
0 1 Transmit Path
1 0 Disabled
1 1 Receive Path
