3 System Connections and Jumper Settings
3 System Connections and Jumper Settings
All power and signal I/O connections are listed in
. Jumper settings are described in
. LED indicator
states are described in
. Factory default jumper settings are shown in
.
.
1.ASP2_SDOUT
Output
N/A
ASP2_SDOUT I
2
S data from CS53L30 #1;
Left channel corresponds to 1.AIN3, right channel corresponds to 1.AIN4
2.ASP1_SDOUT
Output
N/A
ASP1_SDOUT I
2
S data from CS53L30 #2;
Left channel corresponds to 2.AIN1, right channel corresponds to 2.AIN2
2.ASP2_SDOUT
Output
N/A
ASP2_SDOUT I
2
S data from CS53L30 #2;
Left channel corresponds to 2.AIN3, right channel corresponds to 2.AIN4
Table 3-1. External System Connections
Reference Designator Connection Input/Output
Description
J83
+5V_EXT
Input
+5-V external power supply
J89
GND
Input
Board ground
J9
VA_EXT
Input
CS53L30 VA external supply
J14
VP_EXT
Input
CS53L30 VP external supply
J5
UC FLEX C2
Input
Microcontroller programming header
J94
USB
Input/Output USB connection
J29
SERIAL
HEADER
Input/Output CS53L30 Audio Serial Port (MCLK IN, MCLK OUT, LRCK/FSYNC, SCLK, ASP1_
SDOUT, ASP2_SDOUT)
J4
CONTROL
HEADER
Input/Output CS53L30 control port connections (SDA, SCL, INT, RST, MUTE)
• By default, shunts connect the columns marked “FlexGUI CNTL (JUMPER)”. This
connects the onboard microcontroller to the control port of the CS53L30.
• To use external control signals, remove shunts and connect the external controls to the
columns marked “EXT SYS (CABLE)”. Notice the ground connections on Column 3.
J35
S/PDIF OUT
Output
Coaxial S/PDIF digital output
OPT2
S/PDIF OUT
Output
Optical S/PDIF digital output
J53
1.AIN1
Input
Analog mic/line TRS input 1 for CS53L30 #1
J12
1.AIN2
Input
Analog mic/line TRS input 2 for CS53L30 #1
J16
1.AIN3
Input
Analog mic/line TRS input 3 for CS53L30 #1
J20
1.AIN4
Input
Analog mic/line TRS input 4 for CS53L30 #1
J7
2.AIN1
Input
Analog mic/line TRS input 1 for CS53L30 #2
J23
2.AIN2
Input
Analog mic/line TRS input 2 for CS53L30 #2
J26
2.AIN3
Input
Analog mic/line TRS input 3 for CS53L30 #2
J30
2.AIN4
Input
Analog mic/line TRS input 4 for CS53L30 #2
J6
Input header
Input
Analog input 1 and digital mic interface 1 for CS53L30 #1
J17
Input header
Input
Analog input 2 for CS53L30 #1
J19
Input header
Input
Analog input 3 and digital mic interface 2 for CS53L30 #1
J22
Input header
Input
Analog input 4 for CS53L30 #1
J11
Input header
Input
Analog input 1 and digital mic interface 1 for CS53L30 #2
J25
Input header
Input
Analog input 2 for CS53L30 #2
J28
Input header
Input
Analog input 3 and digital mic interface 2 for CS53L30 #2
J32
Input header
Input
Analog input 4 for CS53L30 #2
J33
SYNC I/O
Input/Output Synchronization Input/Output for additional CDB53L30
Table 3-2. CDB53L30 Jumper Settings
Jumper Pin Block Connection
Purpose
Position
Function Selected
J31
+5 V
Select +5 V main
supply
+5V_EXT
1
VBUS
+5-V supply source from J83
+5-V supply source from USB VBUS
J2
VA
Select CS53L30 VA
supply source
VA EXT
+1.8 V
CS53L30 VA supply from J9
CS53L30 VA supply from +1.8 V derived from LDO
J13
VP
Select CS53L30 VP
supply source
VP_EXT
+3.6 V
CDB53L30 VP supply from J14
CDB53L30 VP supply from +3.6 V derived from LDO
Table 2-1. Quick-Start Serial Header Signal Descriptions (Cont.)
Header Pin
Direction
Frequency
Description
