CS5378
DS639F3 12
2. CHARACTERISTICS AND SPECIFICATIONS
• Min / Max characteristics and specifications are guaranteed over the Specified Operating Conditions.
• Typical performance characteristics and specifications are derived from measurements taken at nomi-
nal supply voltages and T
A
= 25
°C.
• GND, GND1, GND2 = 0 V, all voltages with respect to 0 V.
SPECIFIED OPERATING CONDITIONS
ABSOLUTE MAXIMUM RATINGS
1. Transient currents up to 100 mA will not cause SCR latch-up.
Parameter Symbol Min Nom Max Unit
Logic Core Power Supply VDDCORE 2.375 2.5 5.25 V
PLL Power Supply VDDPLL 3.135 3.3 5.25 V
I/O Power Supply VDDPAD 3.135 3.3 5.25 V
Ambient Operating Temperature Industrial (-IQ) T
A
-40 - 85 °C
Parameter Symbol Min Max Units
DC Power Supplies Logic Core
PLL
I/O
VDDCORE
VDDPLL
VDDPAD
-0.3
-0.3
-0.3
6.0
6.0
6.0
V
V
V
Input Current, Any Pin Except Supplies (Note 1) I
IN
- ±10 mA
Input Current, Power Supplies (Note 1) I
IN
- ±50 mA
Output Current (Note 1) I
OUT
- ±25 mA
Power Dissipation P
DN
- 500 mW
Digital Input Voltages V
IND
-0.3 VDD+0.3 V
Ambient Operating Temperature (Power Applied) T
A
-40 85 °C
Storage Temperature Range T
STG
-65 150 °C
