DS861PP3 9
CS5346
ANALOG CHARACTERISTICS
Test conditions (unless otherwise specified): VA = 5 V; VD = VLS = VLC = 3.3 V; AGND = DGND = 0 V;
T
A
= +25° C; Input test signal: 1 kHz sine wave; measurement bandwidth is 10 Hz to 20 kHz; Fs = 48/96/192 kHz;
PGA gain = 0 dB; All connections as shown in Figure 7 on page 18 .
3. Valid for Double- and Quad-Speed Modes only.
4. Referred to the typical A/D full-scale input voltage
5. Valid when the microphone-level inputs are selected.
Parameter Symbol Min Typ Max Unit
Analog-to-Digital Converter Characteristics
Dynamic Range (Line Level Inputs)
A-weighted
unweighted
(Note 3) 40 kHz bandwidth unweighted
97
94
-
103
100
98
-
-
-
dB
dB
dB
Total Harmonic Distortion + Noise (Line Level Inputs) (Note 4)
-1 dB
-20 dB
-60 dB
(Note 3) 40 kHz bandwidth -1 dB
THD+N
-
-
-
-
-95
-80
-40
-92
-89
-
-
-
dB
dB
dB
dB
Dynamic Range (Mic Level Inputs)
A-weighted
(Note 3) unweighted
77
74
83
80
-
-
dB
dB
Total Harmonic Distortion + Noise (Mic Level Inputs) (Note 4)
-1 dB
-20 dB
(Note 3) -60 dB
THD+N
-
-
-
-80
-60
-20
-74
-
-
dB
dB
dB
Interchannel Isolation (Line Level Inputs)
(Mic Level Inputs)
-
-
90
80
-
-
dB
dB
A/D Full-scale Input Voltage 0.51*VA 0.57*VA 0.63*VA V
pp
Gain Error - -  10 %
Interchannel Gain Mismatch - 0.1 - dB
Microphone - Level Input Characteristics
Preamplifier Gain 31
35.5
32
40
33
44.7
dB
V/V
Interchannel Gain Mismatch - 0.1 - dB
Input Impedance (Note 5) - 60 - k
