8 DS861PP3
CS5346
3. CHARACTERISTICS AND SPECIFICATIONS
RECOMMENDED OPERATING CONDITIONS
AGND = DGND = 0 V; All voltages with respect to ground.
ABSOLUTE MAXIMUM RATINGS
AGND = DGND = 0 V All voltages with respect to ground. (Note 1)
Notes: 1. Operation beyond these limits may result in permanent damage to the device.
Normal operation is not guaranteed at these extremes.
2. Any pin except supplies. Transient currents of up to ±100 mA on the analog input pins will not cause
SCR latch-up.
Parameters Symbol Min Nom Max Units
DC Power Supplies: Analog
Digital
Logic - Serial Port
Logic - Control Port
VA
VD
VLS
VLC
4.75
3.13
3.13
3.13
5.0
3.3
3.3
3.3
5.25
3.47
5.25
5.25
V
V
V
V
Ambient Operating Temperature (Power Applied) Commercial T
A
-40 - +85  C
Parameter Symbol Min Max Units
DC Power Supplies: Analog
Digital
Logic - Serial Port
Logic - Control Port
VA
VD
VLS
VLC
-0.3
-0.3
-0.3
-0.3
+6.0
+3.63
+6.0
+6.0
V
V
V
V
Input Current (Note 2) I
in
-  10 mA
Analog Input Voltage V
INA
AGND-0.3 VA+0.3 V
Digital Input Voltage Logic - Serial Port
Logic - Control Port
V
IND-S
V
IND-C
-0.3
-0.3
VLS+0.3
VLC+0.3
V
V
Ambient Operating Temperature (Power Applied) T
A
-50 +125  C
Storage Temperature T
stg
-65 +150  C
