12
DS861PP3
CS5346
DC ELECTRICAL CHARACTERISTICS
AGND = DGND = 0 V, all voltages with respect to ground. MCLK=12.288 MHz; Fs=48 kHz; Master Mode.
9. Power-Down Mode is defines as RST = Low with all clock and data lines held static and no analog input.
10. Valid with the recommended capacitor values on FILT+ and VQ as shown in the Typical Connection
Diagram.
Parameter
Symbol
Min
Typ
Max
Unit
Power Supply Current
VA = 5 V
(Normal Operation)
VD, VLS, VLC = 3.3 V
I
A
I
D
-
-
41
23
50
28
mA
mA
Power Supply Current
VA = 5 V
(Power-Down Mode)
VLS, VLC, VD = 3.3 V
I
A
I
D
-
-
0.50
0.54
-
-
mA
mA
Power Consumption
(Normal Operation)
VA = 5 V
VD, VLS, VLC = 3.3 V
(Power-Down Mode)
VA = 5V; VD, VLS, VLC = 3.3 V
-
-
-
-
-
-
205
76
4.2
250
93
-
mW
mW
mW
Power Supply Rejection Ratio (1 kHz)
PSRR
-
55
-
dB
VQ Characteristics
Quiescent Voltage
VQ
-
0.5 x VA
-
VDC
Maximum DC Current from VQ
I
Q
-
1
-
A
VQ Output Impedance
Z
Q
-
23
-
k
FILT+ Nominal Voltage
FILT+
-
VA
-
VDC
Microphone Bias Voltage
MICBIAS
-
0.8 x VA
-
VDC
Current from MICBIAS
I
MB
-
-
2
mA
