DS861PP3 27
CS5346
6. REGISTER QUICK REFERENCE
This table shows the register names and their associated default values.
Addr Function 7 6 5 4 3 2 1 0
01h Chip ID PART3 PART2 PART1 PART0 REV3 REV2 REV1 REV0
pg. 28 1 1 0 0 x x x x
02h Power Control Freeze Reserved Reserved Reserved PDN_MIC PDN_ADC Reserved PDN
pg. 28 0 0 0 0 0 0 0 1
03h Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
0 0 0 0 1 0 0 0
04h ADC Control FM1 FM0 Reserved DIF Reserved Mute HPFFreeze M/S
pg. 29 0 0 0 0 0 0 0 0
05h MCLK
Frequency
Reserved MCLK
Freq2
MCLK
Freq1
MCLK
Freq0
Reserved Reserved Reserved Reserved
pg. 30 0 0 0 0 0 0 0 0
06h PGAOut
Control
Reserved PGAOut Reserved Reserved Reserved Reserved Reserved Reserved
pg. 30 0 1 0 0 0 0 0 0
07h PGA Ch B
Gain Control
Reserved Reserved Gain5 Gain4 Gain3 Gain2 Gain1 Gain0
pg. 30 0 0 0 0 0 0 0 0
08h PGA Ch A
Gain Control
Reserved Reserved Gain5 Gain4 Gain3 Gain2 Gain1 Gain0
pg. 31 0 0 0 0 0 0 0 0
09h Analog Input
Control
Reserved Reserved Reserved PGASoft PGAZero Sel2 Sel1 Sel0
pg. 31 0 0 0 1 1 0 0 1
0Ah -
0Bh
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
0 0 0 0 0 0 0 0
0Ch Active Level
Control
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Active_H/L
pg. 32 1 1 0 0 0 0 0 0
0Dh Interrupt Status Reserved Reserved Reserved Reserved ClkErr Reserved Ovfl Undrfl
pg. 32 0 0 0 0 0 0 0 0
0Eh Interrupt Mask Reserved Reserved Reserved Reserved ClkErrM Reserved OvflM UndrflM
pg. 33 0 0 0 0 0 0 0 0
0Fh Interrupt Mode
MSB
Reserved Reserved Reserved Reserved ClkErr1 Reserved Ovfl1 Undrfl1
pg. 33 0 0 0 0 0 0 0 0
10h Interrupt Mode
LSB
Reserved Reserved Reserved Reserved ClkErr0 Reserved Ovfl0 Undrfl0
pg. 33 0 0 0 0 0 0 0 0
