CS4205
DS489PP4 37
5.16 Extended Audio Status/Control Register (Index 2Ah)
PRL Mic ADC Powerdown. When ‘set’, the PRL bit powers down the dedicated Mic ADC and cor-
responding input gain stage. To use the dedicated Mic ADC, clear the PRL bit first.
MADC Mic ADC Ready Status. When ‘set’, the MADC bit indicates the dedicated Mic ADC is ready
to transmit data.
VRM Enable Variable Rate Mic Audio. When ‘set’, the VRM bit allows access to the Mic ADC Rate
Register (Index 34h). This bit must be ‘set’ in order to use variable mic capture rates. The
VRM bit also serves as a powerdown for the Mic ADC SRC block. Clearing VRM will reset the
Mic ADC Rate Register (Index 34h) to its default value and the SRC data path is flushed.
VRA Enable Variable Rate Audio. When ‘set’, the VRA bit allows access to the PCM Front DAC
Rate Register (Index 2Ch) and the PCM L/R ADC Rate Register (Index 32h). This bit must
be ‘set’ in order to use variable PCM playback or capture rates. The VRA bit also serves as
a powerdown for the DAC and ADC SRC blocks. Clearing VRA will reset the PCM Front DAC
Rate Register (Index 2Ch) and the PCM L/R ADC Rate Register (Index 32h) to their default
values. The SRC data path is flushed and the Slot Request bits for the currently active DAC
slots will be fixed at ‘0’.
Default 4000h
D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
0 PRL 0 0 0 0 MADC 0 0 0 0 0 VRM 0 0 VRA
