CS4205
DS489PP4 29
5.5 PC_BEEP Volume Register (Index 0Ah)
Mute PC_BEEP Mute. Setting this bit mutes the PC_BEEP input signal.
PV[3:0] PC_BEEP Volume Control. The PV[3:0] bits control the gain levels of the PC_BEEP input
source to the Input Mixer. Each step corresponds to 3 dB gain adjustment, with 0000 = 0 dB.
The total range is 0 dB to -45 dB attenuation.
Default 0000h. This value corresponds to 0 dB attenuation and Mute ‘clear’.
This register has no effect on the PC_BEEP volume during RESET#.
5.6 Phone Volume Register (Index 0Ch)
Mute Phone Mute. Setting this bit mutes the Phone input signal.
GN[5:0] Phone Volume Control. The GN[4:0] bits control the gain level of the Phone input source to
the Input Mixer. Each step corresponds to 1.5 dB gain adjustment, with 01000 = 0 dB. The
total range is +12 dB to -34.5 dB attenuation. See Table 7 on page 31 for further attenuation
levels.
Default 8008h. This value corresponds to 0 dB attenuation and Mute ‘set’.
D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
Mute 0 0 0 0 0 0 0 0 0 0 PV3 PV2 PV1 PV0 0
D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
Mute 0 0 0 0 0 0 0 0 0 0 GN4 GN3 GN2 GN1 GN0
