Technical Specifications
27
7 Technical Specifications 1
Table 15, Table 16 and Table 17 define the TP-107V / TP-107AV / RC-108 /
RC-116 technical specifications.
Table 15: Technical Specifications of the TP-107V
INPUT: 1 XGA on a 15-pin HD connector, 1 CAT 5 on an RJ-45 connector (LINE IN)
OUTPUTS: 1 CAT 5 on an RJ-45 connector (LINE OUT)
MAX. OUTPUT LEVEL: 1.5Vpp
HIGHEST RESOLUTION: UXGA, 1080p
S/N RATIO:
61dB @5MHz
CONTROLS: Slide switches BIT: ID BIT (PIN 4); horizontal and vertical sync inversion;
RS-232, RS-485, RS-485 TERM, PROGRAM
COUPLING: AC
POWER SOURCE: See Table 1
DIMENSIONS: 12cm x 6.95cm x 2.44cm (4.7" x 2.74" x 0.96"), W, D, H
WEIGHT: 0.3kg (0.66lbs) approx.
ACCESSORIES: Power supply, mounting bracket, 19” rack adapters,
Combined K-NET and CAT 5 2 cables (see Table 1)
Table 16: Technical Specifications of the TP-107AV
INPUTS: 1 XGA on a 15-pin HD connector, 1 CAT 5 on an RJ-45 connector (LINE IN)
1 stereo on 3.5mm phones
OUTPUTS: 1 CAT 5 on an RJ-45 connector (LINE OUT)
MAX. OUTPUT LEVEL: VIDEO: 1.5Vpp AUDIO: 1.7Vpp
BANDWIDTH (-3dB): AUDIO: 21kHz
S/N RATIO: VIDEO: 61dB @5MHz AUDIO: 78dB
CROSSTALK (all hostile): VIDEO: -55.5dB @50MHz, video into audio
CONTROLS:
Slide switches bit: ID BIT (PIN 4), horizontal and vertical sync inversion;
RS-232, RS-485, RS-485 TERM, PROGRAM
COUPLING: VIDEO: AC AUDIO: AC
AUDIO THD + NOISE: 0.1%
AUDIO 2nd HARMONIC: 0.02%
POWER SOURCE:
See Table 1
DIMENSIONS: 12cm x 6.95cm x 2.44cm (4.7" x 2.74" x 0.96"), W, D, H
WEIGHT: 0.3kg (0.66lbs) approx.
ACCESSORIES: Power supply, mounting bracket, 19” rack adapters,
K-NET and CAT 5 cables (see Table 1)
Table 17: Technical Specifications of the RC-108 / RC-116
CONTROLS: RS-485, RS-232
DIMENSIONS: RC-108: 12cm x 6.95cm x 2.44cm (4.7" x 2.74" x 0.96"), W, D, H
RC-116: 18.4cm x 11.4cm x 2.65cm (7.24" x 4.5" x 1.05"), W, D, H
WEIGHT: RC-108: 0.3kg (0.66lbs) approx.
RC-116: 0.6kg (1.32lbs) approx.
1 Specifications are subject to change without notice
2 C-STP+KNET-6
