Overview
7
In addition, the TP-122:
Can power or be powered by the transmitter over the same CAT 5 cable
Can change the polarity of decoding H and V Sync for video
Includes EQ. and level controls
Allows an operation range of more than 300ft. (more than 100 meters)
over standard CAT 5 cable
Is 12V DC fed
3.3 Controlling via the RC-108 and RC-116 Presentation Controllers
The RC-108 and RC-116 are presentation controller units designed specifically
to control a system 1 . Each presentation controller has the appropriate number of
input selector buttons 2 , an RS-485 and 12V port and an RS-232
9-pin D-sub port for control and firmware upgrade.
3.4 Recommendations for Achieving the Best Performance
Achieving the best performance means:
Connecting only good quality connection cables 3 , thus avoiding
interference, deterioration in signal quality due to poor matching, and
elevated noise levels (often associated with low quality cables)
Avoiding interference from neighboring electrical appliances that may
adversely influence signal quality, and positioning your Kramer
BoardView Kit away from moisture, excessive sunlight and dust
Caution – No operator-serviceable parts inside unit.
Warning – Use only the Kramer Electronics input power
wall adapter that is provided with this unit 4 .
Warning – Disconnect power and unplug unit from wall
before installing or removing device or servicing unit.
1 Up to eight and up to 16 units, respectively
2 Eight and 16 buttons, respectively
3 The combined CAT 5 and K-NET cable: C-STP+KNET-6
4 For example: model number AD2512C, part number 2535-000251
