1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups 1 that are clearly defined
by function.
Congratulations on purchasing your
Kramer BoardView™ kit, which is ideal
for:
Presentation and multimedia applications
Long range graphics distribution for schools, hospitals, laboratories,
security, and stores
This user manual 2 is supplied with each kit (see Table 1) and each individual
unit (see Table 2).
Table 1: Board View Package Options
BroadView
Kit Name
Machines
Included
Combined STP
CAT 5 and K-NET 3
Cables 4 Provided
Power Adapter
Provided (12V DC) 5
Recommended
Controller
2V Two TP-107V
One TP-120 1 1.25A N/A
2AV Two TP-107AV
One TP-122 1 1.25A N/A
4V Four TP-107V
One TP-120 3 2.1A RC-108
4AV Four TP-107AV
One TP-122 3 2.1A RC-108
8V Eight TP-107V
One TP-120 7 5A RC-116
8AV Eight TP-107AV
One TP-122 7 5A RC-116
You can also purchase additional single units to add to the system, as defined
in Table 2:
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:
Format/Standards Converters; GROUP 5: Twisted-Pair Solutions; GROUP 6: Specialty AV Products; GROUP 7: Scan
Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and
Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com
3 K-NET is a proprietary Kramer protocol for interconnecting Kramer units
4 See section 1.1
5 Adding additional single units to a kit will probably change the power requirements
