KRAMER: SIMPLE CREATIVE TECHNOLOGY

Configuring a TP-107V / TP-107AV System

16

5 Configuring a TP-107V / TP-107AV System

This section describes how to:

Connect the

TP-107V / TP-107AV (see section 5.1)

Configure a

TP-107AV / TP-122 kit with an RC-108 / RC-116 controller

(see section 5.2)

Wire the CAT 5 LINE IN / LINE OUT RJ-45 Connectors (see section 5.3)
Connect a PC (see section 5.4)
Connect via the RS-485 terminal block connector (see section 5.5)
Use the dipswitches (see section 5.6)

5.1 Connecting the TP-107V / TP-107AV

To connect the

TP-107AV

1

as illustrated in the example in Figure 13, do the

following:

1. Connect an XGA source (for example, a computer graphics source) to the

XGA IN 15-pin HD computer graphics connector and an audio source to

the Audio IN 3.5mm mini jack, for example, using a Kramer

C-GMA/GMA cable (VGA HD15M +Audio jack to VGA HD15M

+Audio jack)

2

.

2. Connect the LINE OUT RJ-45 connector to the LINE IN RJ-45 connector

on the next

TP-107AV in the chain or to the LINE IN RJ-45 connector of

a receiver (for example, the Kramer

TP-120

3

for the

TP-107V, or TP-122

for the

TP-107AV), via STP cabling

4

(with a range of more than 300ft

(>100m)).

3. Connect the LINE OUT RJ-45 connector of the previous

TP-107AV unit

to the LINE IN RJ-45 connector on the

TP-107AV.

4. Connect the RS-485 and +12V

5

port to the previous and the next

TP-107AV unit or to the RC-108 Presentation Controller

6

.

1 From this section on, the TP-107AV applies also to the TP-107V (except for the audio connection) unless stated otherwise
2 Not supplied. The full list of Kramer cables is on our Web site at http://www.kramerelectronics.com. Alternatively, you can
connect an XGA source to the XGA IN 15-pin HD computer graphics connector, and a separate audio source to the AUDIO
IN 3.5mm mini jack
3 Refer to the separate user manual, which can be downloaded at http://www.kramerelectronics.com
4 For details of how to wire a CAT 5 LINE IN / LINE OUT RJ-45 connector, see section 5.3
5 The 12V DC power supply (provided) is used to power the system (see Table 1)
6 Or alternatively to the RC-116 (see section 3.3)
