Kramer Electronics TP-107AV User Manual
Page 18
Your Line Transmitters and Presentation Controllers
15
Figure 12: RC-116 Underside Panel
Table 10: RC-108 / RC-116 (Underside Panel) Features
#
Feature
Function
1
PROGRAM Switch
Slide upwards to PROGRAM to upgrade to the latest Kramer firmware
(see
section 6), slide downwards for normal operation
2
RS-485 TERM. Switch
Set the switch to the left to ON for RS-485 Line Termination with 120
3
NULL MODEM MODE
Switch
Set to NULL MODEM MODE to connect a PC to the unit, using the Null-
modem adapter; otherwise connect without a null-modem adapter
