KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
28
NOTE
: Some
VS-808YC
devices are equipped with a different type of Atmel Flash
memory. In such a case, the update procedure stops at the Blank Check stage
and a “Blank Check Failed” message appears at the end of the window.
Go back to step 4 and select device AT89C51RD2. Repeat all the following steps.
11. Close the “ Atmel – Flip” window.
12. Disconnect the power on the
VS-808YC.
13. Disconnect the RS-232 rear panel port on the
VS-808YC unit from the
Null modem adapter.
14. Connect the power on the
VS-808YC
Upon initialization, the new
VS-808YC software version shows in the
7-segment Display
11 Technical Specifications
Table 6 includes the technical specifications:
Table 6: Technical specifications
1
of the VS-808YC 8x8 s-Video / Audio Matrix Switcher
INPUTS:
8 s-Video, 1 Vpp/75 (Y), 0.3Vpp/75 (C) on 4-pin connectors
8 balanced stereo audio +
4dBm/50k
on detachable terminal blocks
OUTPUTS:
8 s-Video, 1 Vpp/75 (Y), 0.3Vpp/75 (C) on 4-pin connectors
8 balanced stereo audio +
4dBm/50
on detachable terminal blocks
MAX. OUTPUT LEVEL:
VIDEO: 2.6Vpp
AUDIO: 26dBm
BANDWIDTH (-3dB):
VIDEO: 70MHz, Fully Loaded
AUDIO: >40kHz
DIFF. GAIN:
0.05%
DIFF. PHASE:
0.03 Deg
K-FACTOR:
<0.05%
S/N RATIO:
VIDEO: 80dB
AUDIO: 82dB
CROSSTALK (all hostile): VIDEO: -61dB
AUDIO: -91dB @1kHz
CONTROLS:
Front panel buttons, Infrared remote control transmitter, RS-232, RS-485
COUPLING:
VIDEO: Y:DC; C: AC
AUDIO: INPUT: AC; OUTPUT: DC
AUDIO THD + NOISE:
0.029%
AUDIO 2nd HARMONIC: 0.021%
POWER SOURCE:
100-240V AC, 50/60Hz; 21VA
DIMENSIONS:
19-inch (W), 7-inch (D) 2U (H) rack-mountable
WEIGHT:
2.7kg (6lbs.) approx.
ACCESSORIES:
Power cord, Null-modem adapter, Windows®-based Kramer control software,
Infrared remote control transmitter
OPTIONS:
External remote IR receiver cable
2
1 Specifications are subject to change without notice
2 P/N: C-A35M/IRR-50
