Operating the VS-808YC
21
8.5.2 Recalling an Input/Output Configuration
To recall an input/output configuration, do the following:
1. Press the RCL button.
The RCL button blinks.
2. Press the appropriate Input / Output button (the button # corresponding to
the setup #). If in the CONFIRM mode, that setup configuration will blink
in the STATUS 7-segment Display, together with the RCL button and the
TAKE button, and will only be implemented after pressing the TAKE button.
The memory recalls the stored data from that reference.
Tip : If you cannot remember which of the 16 input/output configurations is the one
that you want, set the VS-808YC to the CONFIRM mode and manually scan all
the input/output configurations until you locate it.
8.5.3 Deleting an Input/Output Configuration
To delete an input/output configuration, do the following:
1. Press the STO and RCL buttons simultaneously.
Both the STO and RCL buttons blink.
2. Press the appropriate Input / Output button.
This erases that specific input/output configuration from the memory,
leaving it empty and available 1 .
8.6 Locking the Front Panel
To prevent changing the settings accidentally or tampering with the unit via
the front panel buttons, lock 2 your VS-808YC. Unlocking releases the
protection mechanism.
To lock the
VS-808YC:
Press the LOCK button for more than two seconds, until the LOCK button
is illuminated
The front panel is locked. Pressing a button will have no effect, except to
cause the LOCK button to blink 3
1 Storing a new configuration over a previous configuration (without deleting it first) replaces the previous configuration
2 Nevertheless, even though the front panel is locked you can still operate via RS-232 or RS-485, as well as via the Kramer
IR Remote Control Transmitter
3 Warning that you need to unlock to regain control via the front panel
