Contents
ii
9 Connecting to the VP-88K via your Browser 28
9.1 Connecting to the VP-88K User Manual via your Browser 28
9.2 The Main Switching Matrix Page 30
9.2.1 Switching an Input to an Output 30
9.2.2 Setting the AFV Mode 31
9.2.3 Operating in the Offline Mode 32
9.2.4 Storing and Recalling Setups 33
9.2.5 Locking the Front Panel Buttons 35
9.3 Audio Input Gain Control Page 35
9.4 The Configuration Page 36
10 Flash Memory Upgrade 37
11 Technical Specifications 38
12 Communication Parameters 39
13 Tables of ASCII Codes for Serial Communication (Protocol 3000) 39
14 Tables of Hex Codes for Serial Communication (Protocol 2000) 40
15 Kramer Protocol 42
15.1 Switching Protocols 42
15.1.1 Switching Protocols via the Front Panel Buttons 43
15.1.2 Switching Protocols via Protocol Commands 43
15.2 Kramer Protocol 3000 43
15.2.1 Protocol 3000 Syntax 43
15.2.2 Command Parts Details 45
15.3 Kramer Protocol 2000 51
Figures
Figure 1: VP-88K RGBHV/Balanced Audio Matrix Switcher Front Panel 4
Figure 2: VP-88K RGBHV/Balanced Audio Matrix Switcher Rear View 6
Figure 3: Connecting the VP-88K RGBHV/Balanced Audio Matrix Switcher 9
Figure 4: Wiring a Balanced Stereo Audio Input/Output 10
Figure 5: Wiring an Unbalanced Stereo Audio Output 11
Figure 6: Wiring an Unbalanced Source to a Balanced Input 11
Figure 7: Connecting to the VP-88K via RS-232 using a PC 11
Figure 8: Local Area Connection Properties Window 13
Figure 9: Internet Protocol (TCP/IP) Properties Window 14
Figure 10: Connect Window 15
Figure 11: Device Properties Window 16
Figure 12: VP-88K DIP-switches 16
Figure 13: Status Display Immediately After Turn On 20
Figure 14: Status Display 5 Seconds After Turn On 20
Figure 15: Status Display During Normal Operation 21
Figure 16: Status Display Showing OUTPUT 3, Gain -4.5 21
Figure 17: Configuration Button Numbering 22
Figure 18: Status Display OUTPUT 8 Flashing 23
