KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VP-1201 12x1 XGA Switcher / Scanner

The

VP-1201 features:

A bandwidth of 400MHz for RGB signals
Input signal detection
Manual switching or automatic scanning of inputs (or Valid-Only inputs)
Signal switching delay time, ranging from 1 to 16 seconds

Control the

VP-1201 using the front panel buttons, or remotely via:

RS-485 or RS-232 serial commands transmitted by a touch screen system,

PC, or other serial controller
ETHERNET
The Kramer

RC-IR1 Infra-Red Remote Control Transmitter

The

VP-1201 is dependable, rugged and fits into one vertical space (1U) of a

standard 19" rack.
To achieve the best performance:

Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise-

levels (often associated with low quality cables)
Avoid interference from neighboring electrical appliances and position

your Kramer

VP-1201 away from moisture, excessive sunlight and dust

4 Your VP-1201 12x1 XGA Switcher / Scanner

Figure 1 illustrates the front and rear panels of the

VP-1201. Table 1 and

Table 2 define the front and rear panels of the

VP-1201, respectively.

Previously known as the IR-1/IR-1-01
