5-4 61200290L1-1G
Section 5, Statistics MX2800 M13 Multiplexer User Manual
Figure 5-4. DS3 24-Hour Alarm History Screen
NOTE
When a > or < symbol appears in the upper corner of the screen, use the
right and left arrow keys on the keyboard to scroll right or left to view
additional information. See the upper right-hand corner of
Figure 5-4 .
Performance Parameters
View performance parameter information for the network in one of the three time period selections. Infor-
mation in these fields is for the given time period since the last reset. When viewing the 24-hour history
statistics screen, use the left and right arrow keys to scroll through all 96 15-minute intervals. See
Figure
5-5 on page 5-5, Figure 5-6 on page 5-6, and Figure 5-7 on page 5-7 for examples of the performance
parameter screens.
Descriptions of the fields in each screen follow.
