MX2800 M13 Multiplexer User Manual
Transaction Language 1 (TL1), Section 9
61200290L1-1G
9-5
The MX2800 specifically uses quoted line(s) in
REPT-ALM
and
REPT-EVT
Autonomous messages. The
REPT-ALM
message has the following quoted line format:
The
NTFCNCDE
field contains one of the following values:
• CL indicates alarm cleared.
• TC indicates transient condition.
• MN indicates minor.
• MJ indicates major.
• CR indicates critical.
The
REPT-EVT
message has the following quoted line format:
The CONDEFF field will contain one of the following values:
• CL indicates standing condition cleared.
• SC indicates standing condition raised.
• TC indicates transient condition.
For possible CONDTYPE codes for both REPT-ALM
and REPT-EVT quoted lines, see the condition types
on page 9-12 and
on page 9-16, respectively.
Refer to the section
on page 9-11 for a list of Autonomous messages currently
supported by the MX2800.
4. TL1 COMMANDS
As stated in
on page 9-3, the general format for a TL1 command is as follows:
Areas of concentration for TL1 support in the MX2800 include session initiation, session termination, and
system event reporting.
lists the commands currently supported by the MX2800.
NOTE
The Target ID (
tid
) is the same as the Unit ID. Refer to the
