MX2800 M13 Multiplexer User Manual Installation and Operation, Section 2
61200290L1-1G 2-9
Establishing Terminal Connection
NOTE
A Telnet menu session has priority over a terminal menu session through
the craft port. If a terminal menu session is active when a
Telnet menu
session is initiated, the terminal menu session will be disabled while the
Telnet menu session is active.
To connect the MX2800 to a VT100 terminal, follow this procedure:
1. Configure the VT100 terminal for 9600, 19200, 38400, or 57600 baud, 8-bit characters, no parity, and
one stop bit (xxxx, 8N1).
2. Using the ADTRAN-provided terminal interface cable adapter, connect the DTE port of a terminal to
the 8-pin modular jack labeled CRAFT on the MX2800 front panel.
3. Initialize the terminal session.
4. Press E NTER
repeatedly until the username prompt appears.
5. Enter the username. The factory default username is adtran. The password prompt appears.
6. Enter the password. The factory default password is adtran. The Main Menu appears. See
Figure
2-5 on page 2-10.
Main Menu
Make selections on the Main Menu by entering the number corresponding to the chosen parameter or the
desired key strokes. Refer to
Navigating Within the Menus on page 2-10
NOTE
A new Telnet session may take priority over an existing one if a username
and password are provided that have ADMIN privileges
