Table 9-7. tl1 editing data dictionary for ds2 -23, Table 9-7 – ADTRAN MX2800 M13 User Manual
Page 147
MX2800 M13 Multiplexer User Manual
Transaction Language 1 (TL1), Section 9
61200290L1-1G
9-23
contains entries that are used to edit or retrieve options for the DS2 portion of the MX2800.
When performing TL1 edit commands from this table, the value of
rr
should be T2 and the
value
should be one of the following:
201 - DS2#1
202 - DS2#2
.
.
.
207 - DS2#7
Table 9-7. TL1 Editing Data Dictionary for DS2
Keyword
Type
Domain
Description
DIAGDS2TESTSTATE
ENUM
One of the following:
• DATAMODE
• NETWORK
Identifies DS2 Diagnostic Loopback
• NETWORK selects the available loopback
• DATAMODE ends a test in progress
DS2AISRLY
Y/N
Y or [N]
Identifies status of DS2 AIS alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
DS2CFGMODE
ENUM
One of the following:
• T1
• E1
Identifies DS2 Configuration
• T1 sets DS2 configuration to M12 (4xT1).
• E1 sets DS2 configuration to G.747
(3xE1).
DS2LOSRLY
Y/N
Y or [N]
Identifies status of DS2 LOS alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
DS2RAIRLY
Y/N
Y or [N
Identifies status of DS2 RAI alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
