Maintenance
123 Radial INPRO oil seal
228 Bearing frame
6. Assemble the shaft assembly and bearing frame:
a) Coat the outer races of the bearings with a compatible oil.
b) Coat the internal bearing surfaces of the bearing frame with a compatible oil.
c) Position the oil rings in the grooves of the shaft.
109A Thrust-bearing end cover
122 Shaft
123A Thrust deflector
228 Bearing frame
358E Oil ring inspection plug
360A Gasket
370N Bearing-frame screw
390C Thrust-bearing end-cover shim
469P Oil ring retainer
84 Model 3700, API Type OH2 / ISO 13709 1st and 2nd Ed. / API 610 8/9/10/11th Ed. Installation, Operation, and Maintenance
