Product Description
Nameplate on the pump casing using metric units
Nameplate field Explanation
MODEL Pump model
SIZE Size of the pump
FLOW Rated pump flow, in gallons per minute
HEAD Rated pump head, in feet
RPM Rated pump speed, in revolutions per minute
HYDRO PRESS Hydrostatic pressure at 38°C, in pounds per square inch
MAX. DES. WORKING Maximum working pressure at temperature °C, in pounds per square inch
PRESS
S/N
Serial number of the pump
CONT./ITEM NO. Customer contract or item number
IMP. DIA. Rated impeller diameter
MAX. DIA. Maximum impeller diameter
STD. DIM. Standard ANSI dimensional code
MAT'L Material of construction
Nameplate on the bearing frame
Table 4: Explanation of the nameplate on the bearing frame
Nameplate field Explanation
BRG. O. B. Outboard bearing designation
BRG. I. B. Inboard bearing designation
S/N Serial number of the pump
LUBE Lubricant, oil or grease
ATEX nameplate
Nameplate field Explanation
II Group 2
2 Category 2
G/D Pump can be used when gas and dust are present
T4 Temperature class
Model 3700, API Type OH2 / ISO 13709 1st and 2nd Ed. / API 610 8/9/10/11th Ed. Installation, Operation, and Maintenance 17
