7. Check that the HawkJaw Top
wrench
(TW), Middle wrench
(MW) and Bottom wrench (BW)
hang
straight and level when the
drill pipe is against the pipe stop.
8. If the HawkJaw wrenches
(TW, MW, BW) hang tilted
forward or backward, use the
Top Tilt (TT) button or the
Bottom Tilt (BT) button to level
the wrenches. Center the level
bubble (LB).
9. If the HawkJaw wrenches
(TW, MW, BW) hang sloped to
the
right or to the left, push and
hold down Winch Off (WOff) to
back the HawkJaw off the pipe.
Use Lower (L) to lower the
HawkJaw to the rig floor.
Repeat Step 2.
10. Make sure the Pipe stop (PS) is
against
the drill pipe
connection.
NOTE
The HawkJaw performs best when it
hangs aligned with pipe.
Position for Make Up (cont.) Position for Make Up (cont.)
Operation 21
TT BT
WOff
LB
R L
MW BW PS
TW
