Hawk Industries Hawkjaw Jr. Manual 65K-ALS Serial Numbers 4 to 9 - Manual (Page 93)

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
19A
061-30060
999-810835
061-30008
061-30058
061-30050
061-106
061-30049
999-807507
061-20061
061-20070
999-806313
061-91074A033
061-30033
999-806221
061-30023
061-30051
061-30054
999-806289
999-809403
061-91074A027
Pivot Bolt, Pipe Stop
Flat Washer
Pipe Stop Assy.
Pipe Stop Rubber Mount
Adjust Screw
Ball Thrust Bearing *
Adjust Base
Dowl Pin
Shock Sleeve
Adjust Nut, Pipe Stop
Hex Bolt
Lock Washer Set
Index, Pipe Stop
Flex Lock Nut
Adjust Clevis Plate
Adjust Clevis
Pointer
Hex Bolt
Screw SS
Lock Washer Set
1
1
1
1
1
2
1
1
1
1
2
15
1
3
2
1
1
1
11
11
Quantity
Per Unit
Part Name Item Part #
Pipe Stop Assembly
Drawings
* The ball thrust bearing plates have different diameters. The larger diameter bearing plate
must be closer to the center of the adjust base, or the pipe stop system will not move when the
adjust screw is turned.
93 Drawings
30pipest
1/97
