Trouble Shooting
Symptom Remedy
l
Check that air is reaching the Torque hydraulic
valve V5 at Port A. Make sure the hydraulic
power unit is shut down. Disconnect the air
supply to the HawkJaw. Disconnect the grey
Torque air hose to the Torque hydraulic valve V5
Port A. To
disconnect the air hose, push the
hose and collet ring into the valve pilot port. While
holding down the collet ring, pull out the grey air hose.
Place your hand over the disconnected Torque air
hose.
Connect the air supply to the
HawkJaw. A steady blast of air should come out
of the hose. If no air comes out of a hose, the air
hoses are improperly connected within the Left
and Right control handles. See Drawings, p. 110, 112.
If air comes out of the hose when the air supply to
the HawkJaw is
connected, proceed to
the next step.
l
Check that air is reaching the Torque hydraulic
valve V5 at Port B. Disconnect the air supply to
the HawkJaw. Disconnect the blue Torque air
hose to the Torque hydraulic valve V5 Port B. To
disconnect the air hose, push the hose and collet ring
into the valve pilot port. While holding down the collet
ring, pull out the blue air hose. Place your hand over
the disconnected Torque air hose.
Con-
nect the air supply to the HawkJaw. Push in the
Torque air button. A steady blast of air should
come out of the hose. If no air comes out of a
hose, the air hoses are improperly connected
within the Left and Right control handles. See Draw-
ings, p. 110, 112. If air comes out of the blue hose
when the Torque button is pressed, replace the
Torque
hydraulic valve V5. See
Drawings, p. 102, 108.
l
Adjust the wrenches and the pipe stop index to the
OD tool joint size. See Operate, p. 15, 23.
l
Adjust the pipe stop index and the wrenches to the
OD tool joint size. See Operate, p. 15, 23.
Press in the Torque button, and
nothing happens. (cont.)
Dies do not grip pipe across
from each other.
Dies slide on the drill pipe during
make up or break out.
Torque
Button
Dies
78 Troubleshooting
Continued on next page.
