Drawings

135

Drawings

Reducer Assembly

NOTE

* These parts come only in a kit. Part # 031-24625-SRK includes these parts and quantities noted.

Part Name

Quantity

Per Unit

Item

Part #

1

2*

3

4*

5*

6*

7

8

9

10

11

12

13

14*

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

031-R01

031-R02

031-R03

031-R04

031-R05

031-R06

031-24707

031-R08

031-R09

031-R10

031-R11

031-R12

031-R13

031-R14

031-R15

031-R16

031-R17

031-R18

031-R19

031-R20

031-R21

031-R22

031-R23

031-R24

031-R25

031-R26

031-R27

031-R28

031-R29

031-R30

Cap Screw

Shaft Seal

Seal Carrier

Back-up Ring

Quad Ring

"O" Ring

Output Shaft

Thrust Washer

Retainer Ring

Cone

Cup

Bearing Housing

Pipe Plug

"O" Ring

Cup

Cone

Keyed Washer

Lock Washer

Lock Nut

Planet Carrier

Internal Gear

Motor Adapter

Pipe Plug

Bolt

Sun Gear Kit

Thrust Washer

Planet Bearing

Planet Gear

Planet Pin

Retainer Ring

1

1

1

1

1

1

1

1

2

2

2

1

4

2

2

2

1

1

1

1

1

2

4

1

1

2

2

1

1

2

30reduce

11/95
